W1: Tool offset
18.15 Examples
Basic Functions
1606 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
The geometry component of the tool remains unchanged due to _CORMODE = 1. The compensation vector
defined in the WCS (rotation about y axis) must be included in the wear component such that the total tool length
in the figure refers to point P
2
. Therefore, the resulting wear component of the tool is given in relation to the
distance between points P
1
and P
2
.
However, since the wear is evaluated negatively, due to setting data SD42930, the compensation determined in
this way has to be entered in the compensation memory with a negative sign. The contents of the relevant tool
parameters at the end of the program are thus:
The effect of setting data SD42930 on the L3 component in the Y direction can be recognized without the
additional complication caused by the frame rotation.
Example 9:
2 (tool length must be valued in the diameter axis with the factor 0.5) is the value of machine data:
MD20360 $MC_TOOL_PARAMETER_DEF_MASK (definition of tool parameters).
X is diameter axis:
$TC_DP3[1,1] : 10.000 ; Geometry L1 (unchanged)
$TC_DP4[1,1] : 15.000 ; Geometry L2 (unchanged)
$TC_DP5[1,1] : 10.000 ; Geometry L3 (unchanged)
$TC_DP12[1,1] : 2.010 ; Wear L1
;(= 10 -15*cos(30) + 10*sin(30))
$TC_DP13[1,1] : -16.160 ; Wear L2
;(= -15*sin(30) - 10*cos(30))
$TC_DP14[1,1] : -5.000 ; Wear L3
N10 def real _LEN[11]
N20 def real _CORVAL[3]
N30 $TC_DP1[1,1]= 500
N40 $TC_DP2[1,1]= 2
N50 $TC_DP3[1,1]= 3.
N60 $TC_DP4[1,1]= 4.
N70 $TC_DP5[1,1]= 5.
N80 _CORVAL[0] = 1.
N90 _CORVAL[1] = 1.
N100 _CORVAL[2] = 1.
N110 t1 d1 g18 g0 x0 y0 z0 ; ==> MCS position X1.5 Y5 Z4
N120 r1 = settcor(_CORVAL, "g", 1, 1)
N130 t1 d1 x0 y0 z0 ; ==> MCS position X2.5 Y6 Z5
N140 r3 = $TC_DP3[1,1] ; = 5. = (3.000 + 2. * 1.000)
