Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.1 Various interface signals and functions (A2)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1633
Special cases,
errors, ....
"Delete distancetogo (axial)"
After the axes have been stopped with "Delete distancetogo" the next program block is prepared
with the new positions. The axes thus follow a different contour to the one originally defined in the
part program after a "Delete distancetogo".
If G90 is programmed in the block after "Delete distancetogo" it is at least possible to approach the
programmed absolute position. On the other hand, with G91, the position originally defined in the
part program is not reached in the following block.
Corresponding to ... DB21, ... DBX6.2 (delete distance-to-go, channel-specific)
Additional
references
/FB1/ Function Manual Basic Functions; Spindles (S1)
DB31, ...
DBX9.0 - DBX9.2
Controller parameter set switchover (request)
requested parameter set
Edge evaluation: No Signal(s) updated: On request
Signal state 1 or
edge change
0 → 1
-
Signal state 0 or
edge change
1 → 0
-
Signal irrelevant for
...
MD35590 $MA_PARAMSET_CHANGE_ENABLE = 0
Application
example(s)
The binary-coded index of the parameter set to be activated is located in the 3 bits:
• 0 corresponds to the 1st parameter set
• 1 corresponds to the 2nd parameter set
• etc. (max. 6 parameter sets are possible)
Special cases,
errors, ....
Indices 6-7 are mapped onto parameter set 6.
Corresponding to ... DB31, ...DBX69.0-69.2
DB31, ...
DBX9.3
Disable parameter set switchover commands from NC
Locks
Signal state 1 or
edge change
0 → 1
NC should not initiate any parameter set switchovers.
Signal state 0 or
edge change
1 → 0
Parameter set switchover by the NC is enabled.
Corresponding to ... DB31, ... DBX9.0 - DBX9.2
DB31, ...
DBX20.1 Rampfunction generator fast stop
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
A fast stop is triggered by the PLC for the drive (611D). Speed setpoint 0 is therefore entered. The
drive is stopped without a ramp function (regenerative braking).
As soon as the fast stop is recognized by the drive module, the interface signal:
DB31, ... DBX92.1 (Ramp-function generator fast stop active) is returned to the PLC.
DB31, ...
DBX2.2 Delete distancetogo (axisspecific) / spindle reset
