Siemens SINUMERIK 828D

Z1: NC/PLC interface signals
19.12 Feeds (V1)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1741
DB31, ...
DBW136 Analog value: Clamped state
Edge evaluation: no Signal(s) updated: Cyclic
Sensor S1 supplies an analog voltage value: 0 - 10 V. The analog value of the clamped state is
mapped to: 0 - 10000 increments, resolution 1 mV
Note
SIMATIC S7 input module: 0 - 27648 increments, resolution 0.36 mV
Adaptation factor if you change to a spindle with SMI 24: 2,7648
Corresponding to ... DB31, … DBW134 (clamped state)
Drive parameters: p5041[0...5], p5043[0...6]
DB31, ...
DBX138.4 Sensor S4 (piston end position)
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 The piston is in position, i.e. the piston is free to move
Signal state 0 The piston is not in position
Corresponding to ... DB31, … DBX132.4 (Sensor S4 available)
DB31, ...
DBX138.5 Sensor S5 (angular position of the motor shaft)
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 The motor shaft is in position (precondition: The spindle is stationary)
Signal state 0 The motor shaft is not aligned
Corresponding to ... DB31, … DBX132.5 (Sensor S5 available)
