H2: Auxiliary function outputs to PLC
8.1 Brief description
Basic Functions
398 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Application
Path velocity.
Further information
• F function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)
FA functions
Application
Axial velocity.
Further information
• F function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)
Meaning of footnotes
FA (axial feedrate)
Address extension Value
Value range Meaning Value range Type Meaning
Number
8)
1 - 31 Axis number 0.001 ... 999 999.999 REAL Axial feedrate 6
Remarks:
- - -
8)
See "Meaning of footnotes" at the end of the overview.
1)
If tool management is active, neither a T change signal nor a T word is output to the
interface (channel).
2)
The type for the values can be selected by the user via MD22110
$MC_AUXFU_H_TYPE_INT.
3)
Because of the limited display options on the operator panel screens, the REAL type
values displayed are restricted to:
–999 999 999.9999 to 999 999 999.9999
The NC calculates internally but with complete accuracy.
4)
The REAL values are rounded and output to the PLC when setting the machine data:
MD22110 $MC_AUXFU_H_TYPE_INT = 1 (type of H-auxiliary functions is an integer)
The PLC user program must interpret the value transferred according to the machine
data setting.
5)
If the tool management is active, the meaning of the address extension can be
parameterized. Address extension = 0 means the value must be replaced by that of the
master spindle number, i.e. it is equivalent to not programming the address extension.
Auxiliary functions M19 "Position spindle" collected during a block search are not output
to the PLC.
