H2: Auxiliary function outputs to PLC
8.1 Brief description
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
397
Application
Selection of the additive tool offset with reference to an active tool offset.
Further information
• Initial setting: DL = 0
• DL values cannot be output to the PLC via synchronized actions.
• Default setting of the additive tool offset without an active DL function:
MD20272 $MC_SUMCORR_DEFAULT (basic setting of the additive offset without a program)
• Deselection of the additive tool offset: DL = 0
• DL function-specific machine data:
MD22252 $MC_AUXFU_DL_SYNC_TYPE (output time DL functions)
F functions
- - - - - - 0 ... 6 INT Selection of the
additive tool offset
1
Remarks:
The additive tool offset selected with DL refers to the active D number.
F (feedrate)
Address extension Value
Value range Meaning Value range Type Meaning
Number
8)
- - - - - - 0.001 ... 999 999.999 REAL Path feed 6
Remarks:
- - -
8)
See "Meaning of footnotes" at the end of the overview.
DL (additive tool offset)
8)
See "Meaning of footnotes" at the end of the overview.
