H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
401
Spindle-specific auxiliary functions, spindle 1
System function Index <n> Type
Address
extension
Value Group
Spindle right 6 M 1 3 (2)
Spindle left 7 M 1 4 (2)
Spindle stop 8 M 1 5 (2)
Spindle positioning 9 M 1 19 (2)
Axis mode 10 M 1
70
2)
(2)
Automatic gear stage 11 M 1 40 (4)
Gear stage 1 12 M 1 41 (4)
Gear stage 2 13 M 1 42 (4)
Gear stage 3 14 M 1 43 (4)
Gear stage 4 15 M 1 44 (4)
Gear stage 5 16 M 1 45 (4)
Spindle speed 17 S 1 -1 (3)
General auxiliary functions, Part 2
System function Index <n> Type
Address
extension
Value Group
Feed 18 F 0 -1 (1)
Cutting edge selection 19 D 0 -1 (1)
DL 20 L 0 -1 (1)
Tool selection 21 T (0) -1 (1)
Stop (associated) 22 M 0
-1
3)
1
Conditional stop (associated) 23 M 0
-1
4)
1
End of subroutine 24 M 0
-1
5)
1
Nibbling 25 M 0
20
6)
(10)
Nibbling 26 M 0
23
6)
(10)
Nibbling 27 M 0
22
6)
(11)
Nibbling 28 M 0
25
6)
(11)
Nibbling 29 M 0
26
6)
(12)
Nibbling 30 M 0
122
6)
(11)
Nibbling 31 M 0
125
6)
(11)
Nibbling 32 M 0
27
6)
(12)
