Siemens SINUMERIK 828D

H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
402 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Spindle-specific auxiliary functions, spindle 2
System function Index <n> Type
Address
extension
Value Group
Spindle right 33 M 2 3 (72)
Spindle left 34 M 2 4 (72)
Spindle stop 35 M 2 5 (72)
Spindle positioning 36 M 2 19 (72)
Axis mode 37 M 2
70
2)
(72)
Automatic gear stage 38 M 2 40 (74)
Gear stage 1 39 M 2 41 (74)
Gear stage 2 40 M 2 42 (74)
Gear stage 3 41 M 2 43 (74)
Gear stage 4 42 M 2 44 (74)
Gear stage 5 43 M 2 45 (74)
Spindle speed 44 S 2 -1 (73)
Spindle-specific auxiliary functions, spindle 3
System function Index <n> Type
Address
extension
Value Group
Spindle right 45 M 3 3 (75)
Spindle left 46 M 3 4 (75)
Spindle stop 47 M 3 5 (75)
Spindle positioning 48 M 3 19 (75)
Axis mode 49 M 3
70
2)
(75)
Automatic gear stage 50 M 3 40 (77)
Gear stage 1 51 M 3 41 (77)
Gear stage 2 52 M 3 42 (77)
Gear stage 3 53 M 3 43 (77)
Gear stage 4 54 M 3 44 (77)
Gear stage 5 55 M 3 45 (77)
Spindle speed 56 S 3 -1 (76)
Spindle-specific auxiliary functions, spindle 4
System function Index <n> Type
Address
extension
Value Group
Spindle right 57 M 4 3 (78)
Spindle left 58 M 4 4 (78)
Spindle stop 59 M 4 5 (78)
Spindle positioning 60 M 4 19 (78)
Axis mode 61 M 4
70
2)
(78)
Automatic gear stage 62 M 4 40 (80)
