Siemens SINUMERIK 828D

H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
403
Gear stage 1 63 M 4 41 (80)
Gear stage 2 64 M 4 42 (80)
Gear stage 3 65 M 4 43 (80)
Gear stage 4 66 M 4 44 (80)
Gear stage 5 67 M 4 45 (80)
Spindle speed 68 S 4 -1 (79)
Spindle-specific auxiliary functions, spindle 5
System function Index <n> Type
Address
extension
Value Group
Spindle right 69 M 5 3 (81)
Spindle left 70 M 5 4 (81)
Spindle stop 71 M 5 5 (81)
Spindle positioning 72 M 5 19 (81)
Axis mode 73 M 5
70
2)
(81)
Automatic gear stage 74 M 5 40 (83)
Gear stage 1 75 M 5 41 (83)
Gear stage 2 76 M 5 42 (83)
Gear stage 3 77 M 5 43 (83)
Gear stage 4 78 M 5 44 (83)
Gear stage 5 79 M 5 45 (83)
Spindle speed 80 S 5 -1 (82)
Spindle-specific auxiliary functions, spindle 6
System function Index <n> Type
Address
extension
Value Group
Spindle right 81 M 6 3 (84)
Spindle left 82 M 6 4 (84)
Spindle stop 83 M 6 5 (84)
Spindle positioning 84 M 6 19 (84)
Axis mode 85 M 6
70
2)
(84)
Automatic gear stage 86 M 6 40 (86)
Gear stage 1 87 M 6 41 (86)
Gear stage 2 88 M 6 42 (86)
Gear stage 3 89 M 6 43 (86)
Gear stage 4 90 M 6 44 (86)
Gear stage 5 91 M 6 45 (86)
Spindle speed 92 S 6 -1 (85)
Spindle-specific auxiliary functions, spindle 4
System function Index <n> Type
Address
extension
Value Group
