H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
404 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Spindle-specific auxiliary functions, spindle 7
System function Index <n> Type
Address
extension
Value Group
Spindle right 93 M 7 3 (87)
Spindle left 94 M 7 4 (87)
Spindle stop 95 M 7 5 (87)
Spindle positioning 96 M 7 19 (87)
Axis mode 97 M 7
70
2)
(87)
Automatic gear stage 98 M 7 40 (89)
Gear stage 1 99 M 7 41 (89)
Gear stage 2 100 M 7 42 (89)
Gear stage 3 101 M 7 43 (89)
Gear stage 4 102 M 7 44 (89)
Gear stage 5 103 M 7 45 (89)
Spindle speed 104 S 7 -1 (88)
Spindle-specific auxiliary functions, spindle 8
System function Index <n> Type
Address
extension
Value Group
Spindle right 105 M 8 3 (90)
Spindle left 106 M 8 4 (90)
Spindle stop 107 M 8 5 (90)
Spindle positioning 108 M 8 19 (90)
Axis mode 109 M 8
70
2)
(90)
Automatic gear stage 110 M 8 40 (92)
Gear stage 1 111 M 8 41 (92)
Gear stage 2 112 M 8 42 (92)
Gear stage 3 113 M 8 43 (92)
Gear stage 4 114 M 8 44 (92)
Gear stage 5 115 M 8 45 (92)
Spindle speed 116 S 8 -1 (91)
Spindle-specific auxiliary functions, spindle 9
System function Index <n> Type
Address
extension
Value Group
Spindle right 117 M 9 3 (93)
Spindle left 118 M 9 4 (93)
Spindle stop 119 M 9 5 (93)
Spindle positioning 120 M 9 19 (93)
