H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
405
Axis mode 121 M 9
70
2)
(93)
Automatic gear stage 122 M 9 40 (95)
Gear stage 1 123 M 9 41 (95)
Gear stage 2 124 M 9 42 (95)
Gear stage 3 125 M 9 43 (95)
Gear stage 4 126 M 9 44 (95)
Gear stage 5 127 M 9 45 (95)
Spindle speed 128 S 9 -1 (94)
Spindle-specific auxiliary functions, spindle 10
System function Index <n> Type
Address
extension
Value Group
Spindle right 129 M 10 3 (96)
Spindle left 130 M 10 4 (96)
Spindle stop 131 M 10 5 (96)
Spindle positioning 132 M 10 19 (96)
Axis mode 133 M 10
70
2)
(96)
Automatic gear stage 134 M 10 40 (98)
Gear stage 1 135 M 10 41 (98)
Gear stage 2 136 M 10 42 (98)
Gear stage 3 137 M 10 43 (98)
Gear stage 4 138 M 10 44 (98)
Gear stage 5 139 M 10 45 (98)
Spindle speed 140 S 10 -1 (97)
Spindle-specific auxiliary functions, spindle 11
System function Index <n> Type
Address
extension
Value Group
Spindle right 141 M 11 3 (99)
Spindle left 142 M 11 4 (99)
Spindle stop 143 M 11 5 (99)
Spindle positioning 144 M 11 19 (99)
Axis mode 145 M 11
70
2)
(99)
Automatic gear stage 146 M 11 40 (101)
Gear stage 1 147 M 11 41 (101)
Gear stage 2 148 M 11 42 (101)
Gear stage 3 149 M 11 43 (101)
Gear stage 4 150 M 11 44 (101)
Spindle-specific auxiliary functions, spindle 9
System function Index <n> Type
Address
extension
Value Group
