H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
406 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Gear stage 5 151 M 11 45 (101)
Spindle speed 152 S 11 -1 (100)
Spindle-specific auxiliary functions, spindle 12
System function Index <n> Type
Address
extension
Value Group
Spindle right 153 M 11 3 (102)
Spindle left 154 M 12 4 (102)
Spindle stop 155 M 12 5 (102)
Spindle positioning 156 M 12 19 (102)
Axis mode 157 M 12
70
2)
(102)
Automatic gear stage 158 M 12 40 (104)
Gear stage 1 159 M 12 41 (104)
Gear stage 2 160 M 12 42 (104)
Gear stage 3 161 M 12 43 (104)
Gear stage 4 162 M 12 44 (104)
Gear stage 5 163 M 12 45 (104)
Spindle speed 164 S 12 -1 (103)
Spindle-specific auxiliary functions, spindle 13
System function Index <n> Type
Address
extension
Value Group
Spindle right 165 M 13 3 (105)
Spindle left 166 M 13 4 (105)
Spindle stop 167 M 13 5 (105)
Spindle positioning 168 M 13 19 (105)
Axis mode 169 M 13
70
2)
(105)
Automatic gear stage 170 M 13 40 (107)
Gear stage 1 171 M 13 41 (107)
Gear stage 2 172 M 13 42 (107)
Gear stage 3 173 M 13 43 (107)
Gear stage 4 174 M 13 44 (107)
Gear stage 5 175 M 13 45 (107)
Spindle speed 176 S 13 -1 (106)
Spindle-specific auxiliary functions, spindle 11
System function Index <n> Type
Address
extension
Value Group
