H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
407
Spindle-specific auxiliary functions, spindle 14
System function Index <n> Type
Address
extension
Value Group
Spindle right 177 M 14 3 (108)
Spindle left 178 M 14 4 (108)
Spindle stop 179 M 14 5 (108)
Spindle positioning 180 M 14 19 (108)
Axis mode 181 M 14
70
2)
(108)
Automatic gear stage 182 M 14 40 (110)
Gear stage 1 183 M 14 41 (110)
Gear stage 2 184 M 14 42 (110)
Gear stage 3 185 M 14 43 (110)
Gear stage 4 186 M 14 44 (110)
Gear stage 5 187 M 14 45 (110)
Spindle speed 188 S 14 -1 (109)
Spindle-specific auxiliary functions, spindle 15
System function Index <n> Type
Address
extension
Value Group
Spindle right 189 M 15 3 (111)
Spindle left 190 M 15 4 (111)
Spindle stop 191 M 15 5 (111)
Spindle positioning 192 M 15 19 (111)
Axis mode 193 M 15
70
2)
(111)
Automatic gear stage 194 M 15 40 (113)
Gear stage 1 195 M 15 41 (113)
Gear stage 2 196 M 15 42 (113)
Gear stage 3 197 M 15 43 (113)
Gear stage 4 198 M 15 44 (113)
Gear stage 5 199 M 15 45 (113)
Spindle speed 200 S 15 -1 (112)
Spindle-specific auxiliary functions, spindle 16
System function Index <n> Type
Address
extension
Value Group
Spindle right 201 M 16 3 (114)
Spindle left 202 M 16 4 (114)
Spindle stop 203 M 16 5 (114)
Spindle positioning 204 M 16 19 (114)
Axis mode 205 M 16
70
2)
(114)
Automatic gear stage 206 M 16 40 (116)
