H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
408 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Gear stage 1 207 M 16 41 (116)
Gear stage 2 208 M 16 42 (116)
Gear stage 3 209 M 16 43 (116)
Gear stage 4 210 M 16 44 (116)
Gear stage 5 211 M 16 45 (116)
Spindle speed 212 S 16 -1 (115)
Spindle-specific auxiliary functions, spindle 17
System function Index <n> Type
Address
extension
Value Group
Spindle right 213 M 17 3 (117)
Spindle left 214 M 17 4 (117)
Spindle stop 215 M 17 5 (117)
Spindle positioning 216 M 17 19 (117)
Axis mode 217 M 17
70
2)
(117)
Automatic gear stage 218 M 17 40 (119)
Gear stage 1 219 M 17 41 (119)
Gear stage 2 220 M 17 42 (119)
Gear stage 3 221 M 17 43 (119)
Gear stage 4 222 M 17 44 (119)
Gear stage 5 223 M 17 45 (119)
Spindle speed 224 S 17 -1 (118)
Spindle-specific auxiliary functions, spindle 18
System function Index <n> Type
Address
extension
Value Group
Spindle right 225 M 18 3 (120)
Spindle left 226 M 18 4 (120)
Spindle stop 227 M 18 5 (120)
Spindle positioning 228 M 18 19 (120)
Axis mode 229 M 18
70
2)
(120)
Automatic gear stage 230 M 18 40 (122)
Gear stage 1 231 M 18 41 (122)
Gear stage 2 232 M 18 42 (122)
Gear stage 3 233 M 18 43 (122)
Gear stage 4 234 M 18 44 (122)
Gear stage 5 235 M 18 45 (122)
Spindle speed 236 S 18 -1 (121)
Spindle-specific auxiliary functions, spindle 16
System function Index <n> Type
Address
extension
Value Group
