Siemens SINUMERIK 828D

H2: Auxiliary function outputs to PLC
8.2 Predefined auxiliary functions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
409
Spindle-specific auxiliary functions, spindle 19
System function Index <n> Type
Address
extension
Value Group
Spindle right 237 M 19 3 (123)
Spindle left 238 M 19 4 (123)
Spindle stop 239 M 19 5 (123)
Spindle positioning 240 M 19 19 (123)
Axis mode 241 M 19
70
2)
(123)
Automatic gear stage 242 M 19 40 (125)
Gear stage 1 243 M 19 41 (125)
Gear stage 2 244 M 19 42 (125)
Gear stage 3 245 M 19 43 (125)
Gear stage 4 246 M 19 44 (125)
Gear stage 5 247 M 19 45 (125)
Spindle speed 248 S 19 -1 (124)
Spindle-specific auxiliary functions, spindle 20
System function Index <n> Type
Address
extension
Value Group
Spindle right 249 M 20 3 (126)
Spindle left 250 M 20 4 (126)
Spindle stop 251 M 20 5 (126)
Spindle positioning 252 M 20 19 (126)
Axis mode 253 M 20
70
2)
(126)
Automatic gear stage 254 M 20 40 (128)
Gear stage 1 255 M 20 41 (128)
Gear stage 2 256 M 20 42 (128)
Gear stage 3 257 M 20 43 (128)
Gear stage 4 258 M 20 44 (128)
Gear stage 5 259 M 20 45 (128)
Spindle speed 260 S 20 -1 (127)
Tool holder-specific auxiliary functions, T auxiliary functions
System function Index <n> Type
Address
extension
Value Group
Tool selection 261 T 1 -1 129
Tool selection 262 T 2 -1 130
Tool selection 263 T 3 -1 131
Tool selection 264 T 4 -1 132
Tool selection 265 T 5 -1 133
