H2: Auxiliary function outputs to PLC
8.17 Examples
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
471
$MN_AUXFU_GROUP_SPEC[2]='H22' ; Output behavior of auxiliary function group 3
$MN_AUXFU_GROUP_SPEC[8]='H21' ; Output behavior of auxiliary function group 9
$MC_AUXFU_ASSIGN_TYPE[0]="M" ; Description of auxiliary function 1: M40
$MC_AUXFU_ASSIGN_EXTENSION[0]=0
$MC_AUXFU_ASSIGN_VALUE[0]=40
$MC_AUXFU_ASSIGN_GROUP[0]=9
; ... (and analogously for aux. functions 2 to
5)
$MC_AUXFU_ASSIGN_TYPE[5]="M" ; Description of auxiliary function 6: M45
$MC_AUXFU_ASSIGN_EXTENSION[5]=0
$MC_AUXFU_ASSIGN_VALUE[5]=45
$MC_AUXFU_ASSIGN_GROUP[5]=9
$MC_AUXFU_ASSIGN_TYPE[6]="M" ; Description of auxiliary function 7: M1=40
$MC_AUXFU_ASSIGN_EXTENSION[6]=1
$MC_AUXFU_ASSIGN_VALUE[6]=40
$MC_AUXFU_ASSIGN_GROUP[6]=9
; . . . (and analogously for aux. functions 8 to
11)
$MC_AUXFU_ASSIGN_TYPE[11]="M" ; Description of auxiliary function 12: M1=45
$MC_AUXFU_ASSIGN_EXTENSION[11]=1
$MC_AUXFU_ASSIGN_VALUE[11]=45
$MC_AUXFU_ASSIGN_GROUP[11]=9
$MN_AUXFU_GROUP_SPEC[9] = 'H22' ; Output behavior of auxiliary function group 10
$MC_AUXFU_ASSIGN_TYPE[12]="M" ; Description of auxiliary function 13: M2=3
$MC_AUXFU_ASSIGN_EXTENSION[12]=2
$MC_AUXFU_ASSIGN_VALUE[12]=3
$MC_AUXFU_ASSIGN_GROUP[12]=10
$MC_AUXFU_ASSIGN_TYPE[13]="M" ; Description of auxiliary function 14: M2=4
$MC_AUXFU_ASSIGN_EXTENSION[13]=2
$MC_AUXFU_ASSIGN_VALUE[13]=4
$MC_AUXFU_ASSIGN_GROUP[13]=10
$MC_AUXFU_ASSIGN_TYPE[14]="M" ; Description of auxiliary function 15: M2=5
$MC_AUXFU_ASSIGN_EXTENSION[14]=2
$MC_AUXFU_ASSIGN_VALUE[14]=5
$MC_AUXFU_ASSIGN_GROUP[14]=10
$MC_AUXFU_ASSIGN_TYPE[15]="M" ; Description of auxiliary function 16: M2=70
$MC_AUXFU_ASSIGN_EXTENSION[15]=2
Program code Comment
