H2: Auxiliary function outputs to PLC

8.17 Examples

Basic Functions

472 Function Manual, 09/2011, 6FC5397-0BP40-2BA0

$MC_AUXFU_ASSIGN_VALUE[15]=70

$MC_AUXFU_ASSIGN_GROUP[15]=10

$MN_AUXFU_GROUP_SPEC[10] = 'H22' ; Specification of auxiliary function group 11

$MC_AUXFU_ASSIGN_TYPE[16] = "S" ; Description of auxiliary function 17: S2=<all

values>

$MC_AUXFU_ASSIGN_EXTENSION[16]=2

$MC_AUXFU_ASSIGN_VALUE[16]=-1

$MC_AUXFU_ASSIGN_GROUP[16]=11

$MN_AUXFU_GROUP_SPEC[11]='H21' ; Specification of auxiliary function group 12

$MC_AUXFU_ASSIGN_TYPE[17]="M" ; Description of auxiliary function 18: M50

$MC_AUXFU_ASSIGN_EXTENSION[17]=0

$MC_AUXFU_ASSIGN_VALUE[17]=50

$MC_AUXFU_ASSIGN_GROUP[17]=12

$MC_AUXFU_ASSIGN_TYPE[18]="M" ; Description of auxiliary function 19: M51

$MC_AUXFU_ASSIGN_EXTENSION[18]=0

$MC_AUXFU_ASSIGN_VALUE[18]=51

$MC_AUXFU_ASSIGN_GROUP[18]=12

$MN_AUXFU_GROUP_SPEC[12]='H21' ; Specification of auxiliary function group 13

$MC_AUXFU_ASSIGN_TYPE[19]="M" ; Description of auxiliary function 20: M52

$MC_AUXFU_ASSIGN_EXTENSION[19]=0

$MC_AUXFU_ASSIGN_VALUE[19]=52

$MC_AUXFU_ASSIGN_GROUP[19]=13

$MC_AUXFU_ASSIGN_TYPE[20]="M" ; Description of auxiliary function 21: M53

$MC_AUXFU_ASSIGN_EXTENSION[20]=0

$MC_AUXFU_ASSIGN_VALUE[20]=53

$MC_AUXFU_ASSIGN_GROUP[20]=13

Program code Comment
