Siemens SINUMERIK 828D Function Manual

Preface
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
7
Inclined Y axis - - - - ○ -
Synchronous spindle for counterspindle - - - - ○ -
Synchronous spindle for polygon
machining
○-○-○-
Gantry ○○○○○○
Temperature compensation ● ● ● ● ● ●
Drive functions
Safety Integrated: Safe Torque Off,
Safe Brake Control
●●●●●●
Safety Integrated: Safe velocity ○ ○ ○ ○ ○ ○
HMI, CNC programming
ShopMill/ShopTurn HMI functions ● ● ● ● ● ●
DIN/ISO programming with
programGUIDE
●●●●●●
Online ISO dialect interpreter ● ● ● ● ● ●
ShopMill/ShopTurn machining step
programming
○○○○○○
Measuring cycles ○ ○ ○ ○ ○ ○
Simulation in surface display ● ● ● ● ● ●
Simulation in 3D display ○ ○ ○ ○ ○ ○
PLC
SIMATIC S7-200 (integrated) ● ● ● ● ● ●
Basic I/O modules:
PP 72/48D PN
PP 72/48D 2/2A PN (being prepared)
○○○○○○
PLC cycle time 9ms 9ms 6ms 6ms 6ms 6ms
Max. number of PLC operations 24000 24000 24000 24000 24000 24000
Servo-synchronous high-speed PLC
task
●●●●●●
Reaction time to process interrupts
(terminal to terminal)
7.5ms 7.5ms 7.5ms 7.5ms 4.5ms 4.5ms
Max. number of digital inputs/outputs 216/144 216/144 288/192 288/192 360/240 360/240
Max. number of analog inputs/outputs 6/6 6/6 8/8 8/8 10/10 10/10
Commissioning functions
Service Planner (maintenance
scheduler)
●●●●●●
Easy Extend (for managing machine
units)
●●●●●●
Easy Archive (data archiving) ● ● ● ● ● ●
PPU240.2 / 241.2 PPU 260.2 / 261.2 PPU 280.2 / 281.2
BASIC T BASIC M T M T M

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
