Siemens SINUMERIK 828D Function Manual

A3: Axis Monitoring, Protection Zones
2.2 Axis monitoring
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
89
Constraints
Continuous-path mode
For the above-mentioned functions:
• Automatic stopping for releasing the clamps
• Optimized release of the axis clamp through traverse command
• Automatic stopping for setting the clamps
the "Look Ahead" function must be active.
Part-program blocks without path motion (e.g. M82/M83) interrupt continuouspath mode and thus also the "Look
Ahead" function.
Example:
The part-program blocks N320 and N420 are inserted in the programming example used.
N100 G0 X0 Y0 Z0 A0 G90 G54 F500
N101 G641 ADIS=.1 ADISPOS=5
N210 G1 X10 ; Edit
N220 G1 X5 Y20
N310 G0 Z50 ; Retract
N320 M82 ; no path motion
N410 G0 A90 ; Turn rotary table
N420 M83 ; no path motion
N510 G0 X100 ; Approach
N520 G0 Z2
N610 G1 Z-4 ; Edit
N620 G1 X0 Y-20

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
