Siemens SINUMERIK 828D Function Manual

P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
928 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Description of formal parameters of SINUMERIK 840Dsl
The table below lists all formal parameters of the RUN_UP function for the 840Dsl:
Signal
Typ
e
Type Value range Comment
MCPNum I INT Up to 2 Number of active MCP
0: No MCPs available
MCP1In
MCP2In
I POINTER E0.0 to E120.0
or
M0.0 to M248.0
or
DBn DBX0.0 to DBXm.0
Start address for input signals of relevant
machine control panel
MCP1Out
MCP2Out
I POINTER A0.0 to A120.0
or
M0.0 to M248.0
or
DBn DBX0.0 to DBXm.0
Start address for output signals of relevant
machine control panel
MCP1StatSend
MCP2StatSend
I POINTER A0.0 to A124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Currently no significance
MCP1StatRec
MCP2StatRec
I POINTER A0.0 to A124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Currently no significance
MCP1BusAdr
MCP2BusAdr
I INT 1 ... 126
192 .. 223
DP slave: PROFIBUS address
Ethernet MCP: DIP-Setting
MCP1Timeout
MCP2Timeout
I S5time Recommendation: 700ms Cyclic sign-of-life monitoring for machine
control panel
MCP1Cycl
MCP2Cycl
I S5time Recommendation: 200ms Relevant only for P ? ROFIBUS
MCPMPI I BOOL false Available owing to compatibility
MCP1Stop
MCP2Stop
I BOOL 0: Start transfer of machine control
panel signals
1: Stop transfer of machine control
panel signals
DP slave: Slave deactivated
MCP1NotSend
MCP2NotSend
I BOOL 0: Send and receive operation activated
1: Receive machine control panel
signals only
MCPSDB210 I BOOL false Available owing to compatibility
MCPCopyDB77 I BOOL false Available owing to compatibility
