P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
929
MCPBusType I BYTE Righthand half byte (bits 0...3) for MCP1
Lefthand half byte (bits 4...7) for MCP2
b#16#33: PROFIBUS
b#16#44: PROFIBUS on the MPI/DP port
b#16#55: Ethernet
B#16#66: PROFINET
Mixed mode possible, see Chapter "
Configuration machine control panel,
handheld unit, direct keys [Page 894]"
HHU I INT 0, 5 Handheld unit interface
0: No HHU
5: HHU on Ethernet
BHGIn I POINTER E0.0 to E124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Start address
PLC receive data
from HHU
BHGOut I POINTER A0.0 to A124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Start address
PLC transmit data
to HHU
BHGStatSend I POINTER A0.0 to A124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Available owing to compatibility
BHGStatRec I POINTER A0.0 to A124.0
or
M0.0 to M252.0
or
DBn DBX0.0 to DBXm.0
Available owing to compatibility
BHGInLen I BYTE HHU default:
B#16#6 (6 Byte)
Available owing to compatibility
BHGOutLen I BYTE HHU default:
B#16#14 (20 Byte)
Available owing to compatibility
BHGTimeout I S5time Recommendation: 700ms Available owing to compatibility
BHGCycl I S5time Recommendation: 100ms Available owing to compatibility
BHGRecGDNo I INT HHU default: 2 Ethernet DIP switch
BHGRecGBZNo I INT HHU default: 2 Available owing to compatibility
BHGRecObjNo I INT HHU default: 1 Available owing to compatibility
BHGSendGDNo I INT HHU default: 2 Available owing to compatibility
BHGSendGBZNo I Int HHU default: 1 Available owing to compatibility
BHGSendObjNo I INT HHU default: 1 Available owing to compatibility
BHGMPI I BOOL false Available owing to compatibility
