Siemens SINUMERIK 828D Function Manual

P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
941
The same rules apply to channels 3 to 10 as illustrated as examples in the above table in groups 1 and 2.
Declaration of the function
Area
Group 1 C[1] N B A T
Group 2 C[2] N B A T
Group 3 V[.] H[.]
Note
Especially when reading several long strings, the number of usable variables can be less
than 8.
FUNCTION_BLOCK FB 3
VAR_INPUT
Req : BOOL ;
NumVar : INT;
Addr1 : ANY ;
Unit1 : BYTE ;
Column1 : WORD ;
Line1 : WORD ;
Addr2 : ANY ;
Unit2 : BYTE ;
Column2 : WORD ;
Line2 : WORD ;
Addr3 : ANY ;
Unit3 : BYTE ;
Column3 : WORD ;
Line3 : WORD ;
Addr4 : ANY ;
Unit4 : BYTE ;
Column4 : WORD ;
Line4 : WORD ;
Addr5 : ANY ;
Unit5 : BYTE ;
Column5 : WORD ;
Line5 : WORD ;
Addr6 : ANY ;
Unit6 : BYTE ;
Column6 : WORD ;
Line6 : WORD ;
Addr7 : ANY ;
Unit7 : BYTE ;
Column7 : WORD ;
Line7 : WORD ;
