P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
942 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Description of formal parameters
The table below lists all formal parameters of the PUT function.
Addr8 : ANY ;
Unit8 : BYTE ;
Column8 : WORD ;
Line8 : WORD ;
END_VAR
VAR_OUTPUT
Error : BOOL ;
Done : BOOL ;
State : WORD ;
END_VAR
VAR_IN_OUT
SD1 : ANY ;
SD2 : ANY ;
SD3 : ANY ;
SD4 : ANY ;
SD5 : ANY ;
SD6 : ANY ;
SD7 : ANY ;
SD8 : ANY ;
END_VAR
Signal
Ty
pe
Type Range of values Remark
Req I BOOL Job start with positive signal edge
NumVar I INT 1 to 8
(corresponds to use of
Addr1 to Addr8)
Number of variables to be written
Addr1 to Addr8 I ANY [DBName].[VarName] Variable identifiers from
NC Var selector
Unit 1 to Unit 8 I BYTE Area address, optional for
variable addressing
Column 1 to Column
8
I WORD Column address, optional for
variable addressing
Line 1 to Line 8 I WORD Line address, optional for variable
addressing
Error A BOOL Negative acknowledgment of job
or execution of job impossible
Done Q BOOL Job successfully executed
State Q WORD See error identifiers
SD1 to SD8 I/O ANY P#Mm.n BYTE x...
P#DBnr.dbxm.n BYTE x
Data to be written
