P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
943
Error identifiers
If it was not possible to execute a job, the failure is indicated by "logic 1" on status parameter error. The error
cause is coded at the block output State:
Configuration steps
To write NC variables, the same configuration steps are required as for reading NC variables. It is useful to store
the address data of all NC variables to be read or written in a DB.
State Significance Note
WORD H WORD L
1 to 8 1 Access error In high byte number of Var in which
error occurred
0 2 Error in job Incorrect compilation of Var in a job
0 3 Negative acknowledgment, job
not executable
Internal error,
try: Check job,
NC RESET
1 ... 8 4 Data areas or data types do
not match or string is empty
Check data to be written in SD1 to SD8;
in high byte number of the Var in which
error occurred
0 6 FIFO full Job must be repeated since queue is full
0 7 Option not set BP parameter "NCKomm" is not set
1 ... 8 8 Incorrect target area (SD) SD1 to SD8 may not be local data
0 9 Transmission occupied Job must be repeated
1 ... 8 10 Error in variable addressing Unit or column/line contains value 0
0 11 Variable addr. invalid or var. is
read-only
Check Addr (or variable name), area,
unit
0 12 NumVar = 0 Check parameter NumVar
1 to 8 13 (0x0d) ANY data reference incorrect NcVar date required has not been
parameterized
1 to 8 15 (0x0f) User data too long Remedy: Pack fewer variables in the job
or use shorter string variables
