P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
955
PI service: CREACE
Function: Create tool cutting edge
Creation of the cutting edge with the next higher/next unassigned D number for the tool with the transferred T
number in TO, TS (if present). The cutting edge for the OEM cutting edge data is set up simultaneously in the
TUE block - if one is present.
PI service: CREATO
Function: Create tool
Creation of a tool with specification of a T number. The tool is entered as existing in the tool directory area (TV).
The first "cutting edge" D1 (with zero contents) is created for tool offsets in the TO block. D1 (with zero contents)
is also created for the OEM "cutting edge" data in the TUE block - if one is present. If a TU block exists, it will
contain the data set for the tool.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CRCEDN Create new cutting edge
Unit INT 1 ... 10 TOA
WVar1 INT T number of tool for which cutting edge
must be created. A setting of 00000
states that the cutting edge should not
refer to any particular tool (absolute D
number).
WVar2 INT 1 ... 9 or
01 - 31999
Edge number of tool cutting edge
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CREACE Create tool cutting edge
Unit INT 1 ... 10 TOA
WVar1 INT T number
Parameterization
Signal Type Value range Meaning
PIService ANY PI.CREATO Create tool
Unit INT 1 ... 10 TOA
WVar1 INT T number
