P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
956 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
PI service: DELECE
Function: Delete a tool cutting edge
If the T number of an existing tool is specified in parameter “T number” in the PI service, then a cutting edge is
deleted for this particular tool (in this case, parameter “D number” (number of cutting edge to be created) has a
value range of 00001–00009). If a positive T number is specified as a parameter and the tool for the T number
entered does not exist, then the PI service is aborted. If a value of 00000 is entered as the T number (model of
absolute D numbers), then the D number values can range from 00001-31999. If the specified cutting edge does
not exist, then the PI service is aborted in both cases.
PI service: DELETO
Function: Delete tool
Deletes the tool assigned to the transferred T number with all cutting edges (in TO, in some cases TU, TUE and
TG (type 4xx), TD and TS blocks).
Parameterization
Signal Type Value range Meaning
PIService ANY PI.DELETE Delete cutting edge
Unit INT 1 ... 10 TOA
WVar1 INT T number of tool for which cutting edge
must be created. A setting of 00000
states that the cutting edge should not
refer to any particular tool (absolute D
number).
WVar2 INT 1 ... 9
or
01 ... 31999
Edge number of cutting edge that must
be deleted
Parameterization
Signal Type Value range Meaning
PIService ANY PI.DELETO Delete tool
Unit INT 1 ... 10 TOA
WVar1 INT T number
