Table 7-43 Assignment of connector X54
Pin Signal name Type Meaning
1 DO120.0
O
24 V output 0 (group 1)
2 DO120.1 24 V output 1 (group 1)
3 DO120.2 24 V output 2 (group 1)
4 M V Ground
Table 7-44 Assignment of connector X56
Pin Signal name Type Meaning
1 DO120.6
O
24 V output 6 (group 1)
2 DO120.7 24 V output 7 (group 1)
3 DO121.0 24 V output 8 (group 2)
4 M V Ground
Table 7-45 Assignment of connector X57
Pin Signal name Type Meaning
1 DO121.1
O
24 V output 9 (group 2)
2 DO121.2 24 V output 10 (group 2)
3 DO121.3 24 V output 11 (group 2)
4 M V Ground
Table 7-46 Assignment of connector X58
Pin Signal name Type Meaning
1 DO121.4
O
24 V output 12 (group 2)
2 DO121.5 24 V output 13 (group 2)
3 DO121.6 24 V output 14 (group 2)
4 M V Ground
Table 7-47 Technical data for X53, X54 and X56 to X58
Parameter Value
Voltage: Nominal: 24 V
Permissible: 18 V to 30 V
Max. load current: Per output: 0.7 A
Per connector: 1 A
Per output at 100% simultaneity of all 15 outputs: 0.15 A
UL certified rating Each output:
24 V / 0.15 A general, resistive load
24 V / 3.6 W lamp load
24 V / 0.15 A coil load
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
162 Manual, 05/2015, 6FC5397-2DP40-3BA4
