Handwheel X60 / X62
Via X60, you can connect one handwheel either with TTL or difference signals. Alternatively,
you can connect the handwheel via X62. You can connect only one handwheel to the module
because the signals from X60 are fed parallel to X62.
Use switch S2 to switch between TTL and difference signals.
Note
The handwheel is supplied by the MCP module with 5 V / 100 mA. An external power supply
is not permitted.
NOTICE
Handwheel connections
The SINUMERIK 828D software can process up to three handwheels. You can connect two
handwheels to the PPU. You can connect an additional handwheel to the machine control
panel.
Connector designation: X60
Connector type: 15-pin Sub-D socket
Table 7-48 Assignment of connector X60
Pin Signal name Type Meaning
1 P5V V 5 V power supply
2 M V Ground
3 HW1_A I Handwheel pulses track A
4 HW1_XA I Handwheel pulses track A (negated)
5 N.C. - Not assigned
6 HW1_B I Handwheel pulses track B
7 HW1_XB I Handwheel pulses track B (negated)
8 N.C. - Not assigned
9 P5V V 5 V power supply
10 N.C. - Handwheel 2 pulses track A (negated)
11 M V Ground
12 N.C. - Not assigned
13 N.C. - Not assigned
14 N.C. - Not assigned
15 N.C. - Not assigned
Connector designation: X62
Connector type: 12-pin plug connector
Special feature: No galvanic isolation
Max. cable length: 5 m
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 163
