Standard input image
Table 7-59 MCP Interface PN input image
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB112 X111.17 X111.15 X111.13 X111.11 X111.9 X111.7 X111.5 X111.3
EB113 X111.33 X111.31 X111.29 X111.27 X111.25 X111.23 X111.21 X111.19
EB114 X112.17 X112.15 X112.13 X112.11 X112.9 X112.7 X112.5 X112.3
EB115 X112.33 X112.31 X112.29 X112.27 X112.25 X112.23 X112.21 X112.19
EB116 X113.17 X113.15 X113.13 X113.11 X113.9 X113.7 X113.5 X113.3
EB117 X113.33 X113.31 X113.29 X113.27 X113.25 X113.23 X113.21 X113.19
EB118 X114.17 X114.15 X114.13 X114.11 X114.9 X114.7 X114.5 X114.3
EB119 X114.33 X114.31 X114.29 X114.27 X114.25 X114.23 X114.21 X114.19
EB120 X112.38 X112.37 X112.36 X112.35 X111.38 X111.37 X111.36 X111.35
EB121 X114.38 X114.37 X114.36 X114.35 X113.38 X113.37 X113.36 X113.35
EB122 T_Critical
*)
T_High
*)
T_Low
*)
X30.6 X30.7 X30.8 X30.9 X30.10
EB123 - - - X31.6 X31.7 X31.8 X31.9 X31.10
EB124 X55.2 X55.1 X52.3 X52.2 X52.1 X51.3 X51.2 X51.1
EB125 X41.3 X41.2 X41.1 X40.3 X40.2 X40.1 - X55.3
EB126 The current temperature value of the LM77 temperature sensor in degrees Celsius, further information see
below
EB127 Identifier for the 'MCP Interface PN' module is 0x8D
*)
A logical 1 in the appropriate bit means that the associated temperature alarm is present.
Note
Bytes EB126 and EB127
The EB126 and EB127 bytes have significance only when the MCP Interface PN module is
configured as universal component.
The LM77 temperature sensor measures the temperature on the MCP Interface PN module.
The temperature is represented as integer value.
Range of values: -25° C to 100° C
Table 7-60 Temperature representation examples
Temperature in °C Representation in byte EB126
65 0x41
36 0x20
0 0x00
-1 0xFF
-5 0xFB
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
170 Manual, 05/2015, 6FC5397-2DP40-3BA4
