Input image of the handwheels
Table 7-61 Input image for handwheel data
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB m + 0 Handwheel 1 counter status
(16-bit signed, low-order byte equals byte m + 0)
EB m + 1
EB m + 2 Handwheel 2 counter status
(16-bit signed, low-order byte equals byte m + 2)
EB m + 3
Note
Within the SINUMERIK control, the handwheel data is processed directly by the NC and is not
available to the PLC.
Output image
Table 7-62 MCP Interface PN output image
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
AB112 X111.18 X111.16 X111.14 X111.12 X111.10 X111.8 X111.6 X111.4
AB113 X111.34 X111.32 X111.30 X111.28 X111.26 X111.24 X111.22 X111.20
AB114 X112.18 X112.16 X112.14 X112.12 X112.10 X112.8 X112.6 X112.4
AB115 X112.34 X112.32 X112.30 X112.28 X112.26 X112.24 X112.22 X112.20
AB116 X113.18 X113.16 X113.14 X113.12 X113.10 X113.8 X113.6 X113.4
AB117 X113.34 X113.32 X113.30 X113.28 X113.26 X113.24 X113.22 X113.20
AB118 X114.18 X114.16 X114.14 X114.12 X114.10 X114.8 X114.6 X114.4
AB119 X114.34 X114.32 X114.30 X114.28 X114.26 X114.24 X114.22 X114.20
AB120 X56.2 X56.1 X53.3 X53.2 X53.1 X54.3 X54.2 X54.1
AB121 - X58.3 X58.2 X58.1 X57.3 X57.2 X57.1 X56.3
Note
An appropriate bit set to "High" switches the associated output to "High" or the corresponding
LED on. This means that inversion by the operating software is not required.
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 171
