Installation and Commissioning
8-26 7SA6 Manual
C53000-G1176-C133-1
Table 8-13 Jumper setting of relay contact for BO6.
The set nominal currents of the current input transformers are checked on the input/
output board C–I/O–2. All jumpers must be set to the same nominal current, i.e. one
jumper for each input transformer (X61 to X64) and one common jumper X60.
However: There is no jumper X64 for the version with sensitive earth current input
(input transformer T8).
The jumpers X71, X72 and X73 on the input/output board C–I/O–2 are for setting the
bus address and must not be changed. Table 8-14 lists the jumper presettings.
Mounting location:
for housing size
1
/
3
ê in Figure 8-8, slot 19,
for housing size
1
/
2
ê in Figure 8-9, slot 33,
for housing size
1
/
1
ê in Figure 8-10, slot 33 right.
Jumper
Quiescent state open
(NO contact)
Quiescent state closed
(NC contact)
Presetting
X41 1–2 2–3 1–2
Table 8-14 Jumper setting of printed circuit board addresses of binary input/output
boards C-I/O-2
Jumper Presetting
X71 1–2 (H)
X72 1–2 (H)
X73 2–3 (L)
