Siemens SIREMOBIL Iso-C

118 Replacing boards and components
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 118 of 148
For internal use only
Dose-area product measurement device 6.18
x Remove the SIREPHOS cover.
x Replace the dose-area product measurement device.
x Only for dose-area product measurement device from PTW:
- Perform the calibration of the dose-area product measurement device. See
(Dose-area product measurement device "PTW" / p. 65).
x Only for dose-area product measurement device from WELLHÖFER
- Set the slide switch on the dose-area product measurement device to position
"1 cGycm

per pulse / test value 50" (fully to the right).
- See (Dose-area product measurement device "WELLHÖFER" / p. 68).
x Test the accuracy of the dose-area product measurement device. See (Checking the
accuracy of the dose-area product measurement device / p. 70).
x Reinstall the SIREPHOS cover.
x Seal the SIREPHOS cover using sealing compound. See (Covers / p. 20).
