8 Prerequisites
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 8 of 148
For internal use only
Required tools, measurement and auxiliary devices 1.1
NOTE
All tools and measurement and auxiliary devices with the
exception of those marked "*" are listed along with their
specifications in the SPC (Spare Parts Catalog).
x DMM e.g. Fluke 287 99 94 831
x Oscilloscope > 50 MHz e.g. Fluke ScopeMeter 199 CM 73 92 074
x Dose meter e.g. PTW-DIADOS 97 17 612
x Safety tester e.g. BENDER Unimet 1100 51 38 727
x Service PC *
x Service software (refer to SIREMOBIL Iso-C logbook) *
x Connection cable, Service-PC - SIREMOBIL Iso-C e.g. 99 00 440
x 1 set of resolution tests e.g. 28 71 820
x 1 set of radiation filters e.g. 97 98 596
x Center cross e.g. 96 60 051
x Heat conducting paste WPS e.g. 20 48 650
x Special purpose oil (Optimol Optipit) 55 07 525
x Special purpose oil (Slic Pac PTFE) 55 07 517
x Sealing compound 20 49 716
x Standard tool kit*
x 1 set of Allen keys*
x 200 N spring scale e.g. 44 15 113
x Torque wrench, 20 Nm to 100 Nm e.g. 44 30 906
x Torque wrench, 3 Nm to 20 Nm e.g. 70 59 975
x A 30 mm socket key (required for adjusting the brake) *
For SIREMOBIL Iso-C 3D, in addition
x Iso-C 3D calibration phantom 75 51 620
x Luminance meter e.g. SMfit Spotmeter 77 52 848
