Replacing the I.I. 6.11
Checking the temperature indicator 0
x Prior to installing the I.I., check the temperature indicator.
x If the inner square field of the indicator is white, the I.I. did not exceed the temperature
range. Remove the temperature indicator.
x If the indicator is discolored (inner field black), proceed according to IQ document
AX51-030.812.01...
Removal 0
WARNING
Electrical voltage!
¹ See (Safety information / p. 11).
¹ Switch the SIREMOBIL Iso-C off and wait at least > 3
minutes until the high voltage in the system and in the
I.I. mini-voltage supply dissipates.
WARNING
Risk of injury on mechanical parts!
If these guidelines are not followed, minor to moderate injury,
especially to the hands, can occur.
¹ Follow the notes concerning the C-arm carbon fiber
structure.
CAUTION
Risk of injury!
Noncompliance can lead to minor to medium injury and/or
property damage.
The C-arm covers contain counterbalance weights and weigh
approx. 6 kg.
Hold the covers firmly when installing or removing them.
¹ Before the C-arm cover is loosened, the C-arm must be
moved to its middle orbital position. If the C-arm cov-
ers are loosened, the C-arm may not be moved to its
orbital end positions (I.I. or SIREPHOS at the orbital
end position).
VIDEOMED DC
x Move the I.I. into the service position. See (I.I. service position / p. 25).
x Remove the Videomed DC and place it on a clean surface.
x Cover it to prevent contamination. See also (Replacing the VIDEOMED DC / p. 83).
