© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Adjustments / Programs 55
Page 55 of 148
For internal use only
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No".
X
x Switch on fluoro.
x Open the slot diaphragm to where the blades begin to disappear at the edge of the
image.
x Switch off fluoro.
x In the window "Available Functions:" select "FULL FORMAT POSITION" and click
"Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No".
x Select the zoom format.
X
x Switch on fluoro.
x Open the slot diaphragm to where the blades begin to disappear at the edge of the
image.
x Switch off fluoro.
x In the window "Available Functions:" select "ZOOM FORMAT POSITION" and click
"Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No".
x In the window "Available Functions:" select "Enable circle mask" and click "Execute"
x Respond to the query "Do you want to reset the unit" by clicking "No".
x In the window "Available Functions:" select "INIT OFF & STORE POSITION" and click
"Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "Yes". The adjustment
values are stored.
Concluding steps 0
x Switch off the system and switch it back on again.
x Return to the main menu by pressing ESC at the service PC.
x Select the "Data, Backup..." menu.
x Click "parameter" in the Backup window.
x Then click "Backup".
x Enter "slot diaphragm adjusted" under "Remarks for Parameter".
x Then click "OK" . The new position values are stored to disk.
x You can now exit the service program.
