MULTISPOT 2000 6.17
Before installing the new MULTISPOT 2000, set the correct refresh rate. See Table 1.
x Disconnect the SIREMOBIL line voltage plug from the receptacle.
x Replace the MULTISPOT 2000.
x The screws securing the MULTISPOT 2000 are accessible on the underside of the
camera.
x Perform a camera function test after the replacement.
x Generate and program the exposure parameters for the Multispot 2000 according to
the IQ Quick test (see the log book). Record the new exposure parameters in the IQ
Quick test instructions.
50 Hz refresh rate 60 Hz refresh rate
Jumper Position Jumper Position
X4 b X4 a
X5 open X5 open
X6 b X6 a
X7 b X7 a
X8 b X8 a
X9 b X9 a
X10 b X10 a
X11 b X11 a
