120 Replacing boards and components
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 120 of 148
For internal use only
Mouse, external mouse, and PC keyboard 6.20
NOTE
Only applies to SIREMOBIL Iso-C 3D.
x The system comes with a mouse and an external mouse. Both are connected to the
mouse interface of the 3D reconstruction PC by means of a mouse Y-switch. The key-
board is connected to the keyboard interface of the 3D reconstruction PC.
Replacing the mouse 0
x Switch the system off.
x Open the rear panel of the monitor trolley and the cover of the 3D reconstruction PC.
x Replace the mouse. Pull the mouse connector out of the mouse Y-switch, cut the cable
ties at the spring steel band, and pull the cable out of the cable duct.
x Run the cable of the new mouse through the cable duct and along the spring steel band
and reconnect it.
x Reattach the cable from the mouse Y-switch to the keyboard compartment to ensure
that there is sufficient cable length in the keyboard compartment.
x Using cable ties, tie the cable (including the keyboard cable) to the spring steel band
again at a distance of approx. 10 cm.
x Perform a function check of the mouse, the external mouse, and the keyboard.
x Reattach the cover.
Replacing the external mouse 0
x Switch the system off.
x Unplug the external mouse at the rear and replace it with the new external mouse.
x Perform a function check of the mouse, the external mouse, and the keyboard.
Replacing the PC keyboard 0
x Switch the system off.
x Open the rear panel of the monitor trolley and the cover of the 3D reconstruction PC.
x Replace the keyboard. Unplug the keyboard at the 3D reconstruction PC, cut the cable
ties at the spring steel band, and pull the cable out of the cable duct.
x Run the cable of the new keyboard through the cable duct and along the spring steel
band and reconnect it.
x Using cable ties, tie the cable (including the mouse cable) to the spring steel band again
at a distance of approx. 10 cm.
x Perform a function check of the mouse, the external mouse, and the keyboard.
x Reattach the cover.
