Siemens SIREMOBIL Iso-C

© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Adjustments / Programs 77
Page 77 of 148
For internal use only
Configuring the MEMOSKOP 5.16
MEMOSKOP C-E, keyboard emulation 0
There is no keyboard supplied with some SIREMOBIL Iso-C units and installed
MEMOSKOP C-E. When replacing the MEMOSKOP C-E or when changing the configu-
ration, the MEMOSKOP service program should be used.
The help file "C-DATA.hlp" is copied to the service PC during installation of the
MEMOSKOP service program. The "C-DATA.hlp" help file contains descriptions of the pro-
gramming.
Configuring the video frequency 0
After replacing the MEMOSKOP, it will start at a default video frequency (50 Hz). If the mon-
itors were configured for a different frequency, you will have to configure the MEMOSKOP.
Without installed MEMOSKOP keyboard:
x Use the MEMOSKOP service program to modify the configuration.
With installed MEMOSKOP keyboard:
x Select the Technical Setup on the MEMOSKOP (press the CTRL + T keys).
x Press the "2" key and press return. The video frequency menu is selected.
x Depending on the required video frequency, press the right cursor key "->".
"->" = Press the right cursor key
"<-" = Press the left cursor key
After selecting the desired video frequency, press "Return". This configures the video fre-
quency you have just selected. After switching the SIREMOBIL off and on again, the
MEMOSKOP will start up at the correct video frequency.
MEMOSKOP, configuration for the number of existing monitors 0
When you replace the MEMOSKOP, it will be configured for 2 monitors. This configuration
displays USER SETUP and TECHNICAL SETUP on the second monitor. Therefore,
USER SETUP and TECHNICAL SETUP are not visible for SIREMOBIL Iso-C systems with
only one monitor.
Without installed MEMOSKOP keyboard:
"->" pressed 1 time:
"->" pressed 2 times:
"->" pressed 3 times:
"->" pressed 4 times:
60 Hz video frequency
100 Hz video frequency
120 Hz video frequency
50 Hz video frequency
Key "->": (Start "->" "->" "->" "->" ...
Video frequency 50 Hz 60 Hz 100 Hz 120 Hz 50 Hz etc...
Key "<-": "<-" "<-" "<-" "<-" "<-" "<-"
