Basic system operating panel 6.4
x Disconnect the plugs for the operating panel from board D1.
x Remove the cable clamps to the operating panel.
x Remove the Allen screws on the mounting ring (swivel joint of the operating panel).
x Replace the operating panel.
x Reinstall the mounting ring.
x Reconnect the cable.
x Reattach the cable clamp.
x Perform a function test of the operating panel.
