Siemens SIREMOBIL Iso-C

74 Adjustments / Programs
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 74 of 148
For internal use only
Overview of MEMOSKOP C / C-E / C-SUB / C & MOD / C-SUB &
MOD Parameters
5.15
User Setup
x User Setup is selected with the CTRL + U key combination.
x The available functions are described in the SIREMOBIL Iso-C Operating Instructions.
Technical Setup
x Technical Setup is selected with the CTRL + T key combination.
x Enter the password and confirm with [RETURN]
The following functions can be selected depending on the type of MEMOSKOP:
Function: Comments:
Test pattern generation Not for service. Select the necessary test images on the ser-
vice PC.
Video frequency The currently programmed frame rate is shown in the paren-
theses to the right. After downloading the MEMOSKOP or
after replacement, the MEMOSKOP will start up at the
default video frequency (50 Hz). If the monitors are config-
ured for a different video frequency, you must perform "blind"
configuration for the correct video frequency. Refer to "Con-
figuring video frequency".
Number of monitors Allows you to program the number of monitors used (1 or 2)
Hardcopy setup You can configure the connection for hardcopy cameras.
Check whether 5000 is programmed for "4 Max Hardcopy
time" and if not, program this value.
Edge 1 coef set Allows configuration of edge enhancement. Check whether
3 is programmed and if not, program this value.
Edge 2 coef set Allows Configuration of edge enhancement. Check whether
8 is programmed and if not, program this value.
Motion detection setup Configures the motion detector. Check if at MD 1: Threshold
100 and at MD 2:Threshold 120 is programmed, if not, pro-
gram these values.
Circular mask setup Allows you to configure the diameter of the circular mask.
Move text positions Allows you to configure the position of superimposed text.
Date / Time format European: DD MM YY / HH MM
US: MM DD YY / HH MM
System configuration Allows you to read out the current MEMOSKOP configura-
tion.
Keyboard Allows you to program the corresponding keyboard layout
Universal / Roman.
Graphics level Level (brightness) of superimposed text. (Default: 128)
Display of real time clock Yes: Real time clock: date and time are displayed according
to the user setup programming for MEMOSKOP. The real
time clock is active. NO: The real time clock is switched off.
The user setup programming will not affect it.
