88 Replacing boards and components
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 88 of 148
For internal use only
Power Supply M13, +13 V VIDEOMED DC 6.7
WARNING
Electrical voltage!
¹ See (Safety information / p. 11).
¹ Switch the system power supply off and disconnect the
power plug.
x Remove the Plexiglas cover over the power supply. Remove the 4 Allen screws.
x Replace the power supply.
x Check the power supply voltage and adjust it if necessary. See (Checking the operat-
ing voltages / p. 30).
