Siemens SIREMOBIL Iso-C

© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Line voltage adjustment 29
Page 29 of 148
For internal use only
Checking the line voltage on the monitor trolley 2.1
x Jumper X10 for the basic system must be disconnected.
x The monitor, memory device, and other devices, if present, such as a multiformat cam-
era, video printer or video recorder, must be disconnected from the line voltage supply.
Check the secondary voltages for line voltage transformer T1 according to the table.
from test point to test point Voltage Comment
Transformer T1.31 Transformer T1.32 190 V ~ to 205 V ~ cannot be adjusted
Transformer T1.31 Transformer T1.33 230 V ~ to 246 V ~ cannot be adjusted
Line voltage cable
MEMOSKOP, N
Line voltage cable
MEMOSKOP, L
230 V ~ to 246 V ~ cannot be adjusted
Line voltage cable,
Monitor 1, N
Line voltage cable, Mon-
itor 1, L
230 V ~ to 246 V ~ cannot be adjusted
Option: Line voltage cable,
Monitor 2, N
Line voltage cable, Mon-
itor 2, L
230 V ~ to 246 V ~ cannot be adjusted
Option: Line voltage cable
MULTISPOT, N
Line voltage cable MUL-
TISPOT, L
230 V ~ to 246 V ~ cannot be adjusted
Option: Line voltage cable,
Video printer, N
Line voltage cable,
Video printer, L
230 V ~ to 246 V ~ cannot be adjusted
Option: Line voltage cable,
Video recorder, N
Line voltage cable,
Video recorder, L
230 V ~ to 246 V ~ cannot be adjusted
Option: Optical isolation, line
voltage cable, N
Optical isolation, line L
voltage cable
230 V ~ to 246 V ~ cannot be adjusted
