3- 3Checking the operating voltages
Low voltages 0
Check the operating voltages for the SIREMOBIL Iso-C against the values in the table.
from test point to test point Voltage Potentiometer
D1.X31 (0V) D1.X30 (+5 V) + 5.0 V to 5.2 V M14. +5 V/Adj.
D1.X34 (0V) D1.X32 (+15 V) + 14.9 V to 15.1 V M14. +15 V/Adj.
D1.X34 (0V) D1.X33 (-15 V) - 14.8 V to - 15.2 V M14. -15 V/Adj.
D30.X1.8 (0V) D30.X1.9 (+24 V) + 24.0 V to 29.6 V not adjustable
D30.X21.1 (0V) D30.X21.10 (+24 V) + 22.8 V to + 29.5 V not adjustable
D30.X20.1 (0V) D30.X20.3 (+27 V) + 27.3 V to + 27.8 V D30 R115
M13.S- (0V) M13.S+ (+13 V) + 13.1 V to 13.3 V M13.TR1
