© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Adjustments / Programs 59
Page 59 of 148
For internal use only
Full format, slot diaphragm closed 0
X x Apply fluoro briefly.
x Open and close the slot diaphragm display via the keys.
x Align the lines shown on the monitor with the front edges of the slot diaphragm blades.
x In the window "Available Functions:" select "Slot Diaphragm Close Pos - I.I. Full For-
mat" and click "Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No". The slot dia-
phragm remains closed.
Zoom format, slot diaphragm closed 0
x The zoom format is selected automatically.
X
x Apply fluoro briefly.
x Open and close the slot diaphragm display via the keys.
x Align the lines shown on the monitor with the front edges of the slot diaphragm blades.
x In the window "Available Functions:" select "Slot Diaphragm Close Pos - I.I. Zoom For-
mat" and click "Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No". The slot dia-
phragm opens automatically (zoom format).
Zoom format, slot diaphragm opened 0
X x Apply fluoro briefly.
x Open and close the slot diaphragm display via the keys.
x Align the lines shown on the monitor with the front edges of the slot diaphragm blades.
x In the window "Available Functions:" select "Slot Diaphragm Open Pos - I.I. Zoom For-
mat" and click "Execute".
x Close the status window by clicking the OK button.
x Respond to the query "Do you want to reset the unit" by clicking "No".
Enable circle mask 0
x In the "Available Functions:" window select "Enable Circle Mask" and click "Execute".
Close the status window by clicking the OK button. For the query "Do you want to reset
the unit", click "No".
