I.I. voltages 3.1
Voltages E1 / E2 / E3 and A may be taken from the I.I. test protocol and checked or adjusted
against the control test points listed in the table.
Voltage Test point
Ground
point (0V)
Potentiome-
ter for full
format
Potentiome-
ter for zoom
format
Voltage
divider
ratio
E1 UE1 A P10 P11 1:1
E2 UE2 A P6 P7 1:1
E3 UI 15 A P2 P3 1:10000
30 kV, anode UI 30 A P1 P1 1:10000
