Siemens SIREMOBIL Iso-C

114 Replacing boards and components
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 114 of 148
For internal use only
MEMOSKOP C-SUB/ MEMOSKOP C-SUB & MOD 6.16
NOTE
Check the software status of the newly delivered
MEMOSKOP. If the software status of the MEMOSKOP differs
from that of the system, the system software status must be
downloaded to the MEMOSKOP. The MEMOSKOP software
status can be read out in the 2nd line of the User Setup. The
first number describes the MEMOSKOP type. (2=CE; 3=
CE-100/ C/ C & MOD; 4=C-SUB/ C-SUB & MOD).
NOTE
Read and record the parameters for MEMOSKOP C-SUB if
you can select User setup. After replacement, configure the
MEMOSKOP C-SUB, according to the parameters recorded.
x Check the software status of the MEMOSKOP. Download the system software to the
MEMOSKOP if necessary.
x Use the MEMOSKOP Service Software to import the language file.
x Replace the MEMOSKOP C-SUB.
The attachment screws are accessible on the underside of the storage device.
x Set the MEMOSKOP C-SUB to the correct video frequency and configure it for the
number of existing monitors.
See (Configuring the video frequency / p. 77) and (MEMOSKOP, configuration for the
number of existing monitors / p. 77).
x Configure the following parameters in Technical Setup for MEMOSKOP:
Number of Monitors Configure 1 for SIREMOBIL with 1 monitor. Configure 2 for
SIREMOBIL with 2 monitors.
Hardcopy Check whether 5000 is programmed in "4 Max Hardcopy
time". If not, program this value.
Edge 1 coef set Check whether 3 is programmed; if not, program this
value.
Edge 2 coef set Check whether 8 is programmed, If not, program this
value.
Motion detection setup Check whether the following are programmed "MD1:
Threshold" 100 and for "MD2: Threshold" 120. If not, pro-
gram these values.
Date / Time format Set the country-specific format.
Keyboard Set to the keyboard layout being used.
Language Set for language of the country.
Display of realtime clock Configure Yes. Select No only upon customer request.
Display of rotated images Configure Yes.
