Siemens SIREMOBIL Iso-C

© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Replacing boards and components 119
Page 119 of 148
For internal use only
Laser targeting device 6.19
x Remove the SIREPHOS cover.
x Replace the laser diodes after removing the plastic bracket and unsoldering the wires.
x Adjust the laser diodes using the adjustment device supplied with the laser targeting
device.
x Reinstall the SIREPHOS cover.
x Seal the SIREPHOS cover using sealing compound. See (Covers / p. 20).
