84 Replacing boards and components
SIREMOBIL Iso-C SPR2-230.840.01.01.02 © Siemens, 2008
08.08 CS PS SP
Page 84 of 148
For internal use only
x Reconnect the plugs between the VIDEOMED DC and the Compact optics and secure
them with cable ties. In doing this, make sure that the cable or the cable ties do not
extend beyond the edge of the board and that they are located in the recess of the
VIDEOMED DC board.
x Leave the I.I. in the service position.
Checks and adjustments 0
x Switch the system on and rotate the camera from +220 degrees to -220 degrees. When
doing this, the cable in the cable spool must allow for unhindered rotation over the entire
rotation range.
x Check the camera rotation and, if necessary, readjust it. The camera should be able to
rotate 220° +3° or -220° -3° (Check this using the display).
x Check the dose rate and readjust it if necessary.
x Perform the IQ Quick test. First check the resolution. If necessary, adjust the optical
sharpness at the Compact optics.
x If the "Modularis" system is present, perform the isocenter check.
