© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Adjustments / Programs 57
Page 57 of 148
For internal use only
x Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
x In the "Available Functions:" window select "Close Pos - II. Full Format" and click "Exe-
cute".
x Close the status window by clicking the OK button.
x For the query "Do you want to reset the unit", click "No".
x The X-Iris remains in the minimum position.
x Zoom format is automatically selected.
Zoom format, X-Iris closed 0
X x Briefly release fluoro. The X-Iris is displayed on the monitor.
x Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
x In the "Available Functions:" window select "Close Pos - II. Zoom Format" and click
"Execute".
x Close the status window by clicking the OK button.
x For the query "Do you want to reset the unit" click "No".
x The X-Iris is opened automatically.
x Zoom format remains selected.
Zoom format, X-Iris open 0
X x Briefly release fluoro. The X-Iris is displayed on the monitor.
x Use the keys for opening and closing the X-Iris to set the diameter of the superimposed
circle to the size of the X-Iris.
x In the "Available Functions:" window select "Open Pos - II. Zoom Format and click "Exe-
cute".
x Close the status window by clicking the OK button.
x For the query "Do you want to reset the unit", click "No".
Save values and end adjustment 0
x In the "Available Functions:" window select "INIT OFF & STORE VALUES" and click
"Execute".
x Close the status window by clicking the OK button.
x For the query "Do you want to reset the unit", click "Yes".
Concluding tasks 0
Before ending the service program, save the new parameter values to disk (Service PC,
Data menu, Backup).
