© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Replacing boards and components 127
Page 127 of 148
For internal use only
x Reattach the mounting plate including the motor. In doing so, place the toothed belt
over the pulley again, ensuring that the actual value potentiometer and its pulley are not
damaged or bent.
x Retighten the toothed belt of the orbital drive ((1/Fig. 40 / p. 126)). When depressed by
thumb pressure on the opposite side, the belt should give approx. 2 to 3 mm.
x Perform a functional check of the orbital drive. To do this, perform a 3D scan.
