© Siemens, 2008 SPR2-230.840.01.01.02 SIREMOBIL Iso-C
08.08 CS PS SP
Prerequisites 13
Page 13 of 148
For internal use only
WARNING
Risk of injury on mechanical parts!
If these guidelines are not followed, minor to moderate injury,
especially to the hands, can occur.
¹ The C-arm of the system is manufactured from a car-
bon fiber composite material (CFK). In case of damage
of the carbon fiber structure, for example caused by
collision or by cutting or scraping tools, individual car-
bon fibers or carbon fiber bundles can stand out and
on contact cause injuries to the skin or penetrate into
the tissue of the hand.
¹ Before starting work on the C-arm, make sure that the
carbon fiber structures are undamaged (visual inspec-
tion).
¹ If smaller superficial damage is detectable in the
painted area or in the area of the running surface edges
of the C-arm, wear work gloves and remove any pro-
jecting carbon fibers. Then carefully rub the damaged
places flat with a fine emery cloth and seal the dam-
aged surface with paint. A spray paint the color of the
C-arm can be used for this purpose (see Service Tool
Catalog). Remove any carbon fibers lying in the C-arm
profile with a damp sponge or cloth.
¹ If greater damage to the carbon fiber structure indicat-
ing persistent or large-scale destruction of the carbon
fiber structure (e.g. crack formation or flaked off places
in the running surfaces with torn carbon fibers) can be
detected, replace the C-arm.
CAUTION
Electrostatic voltage!
Noncompliance can lead to property damage.
¹ ESD protection guidelines must be followed when per-
forming service.
CAUTION
Risk of being burned by hot parts or components!
Noncompliance can lead to minor or moderate burns, espe-
cially on the hands.
¹ Removing the covers exposes parts or components
(e.g. power components, heat sinks, solenoid brakes)
which may develop temperatures of 50° Celsius when
in operation. To prevent burns, switch the system
power supply off before contacting any parts or com-
ponents and let the system cool off for at least 5 min-
utes before resuming work.
